Oil Separators Filters

Part No: 2901056622

Filter Media: Imported US HV multi-layer borosilicate micro glass fiber composite coalescing media

Filtration Precision: ≤0.1 μm micro oil mist capture

Separation Efficiency: ≥99.999%

Residual Oil Carry-over at Air Outlet: ≤3 ppm

Standard Service Life: 4000–6000 working hours; shorten to 2800h under dusty heavy workshop environment

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20℃ ~ 120℃

Initial Pressure Drop: ≤0.02 MPa

Replacement Alarm Differential Pressure: ≥0.08 MPa

Gross Weight: 4.33 KG

Dimensions (mm)

Flange Outer Diameter: 362mm

Cartridge Outer Diameter: 219mm

Central Inner Hole Diameter: 157mm

Overall Height: 278mm

Application Scenarios

Auto parts precision machining, general machinery foundry, medium injection molding factories, electronic assembly production lines, factory centralized compressed air stations, food packaging low-oil clean air production workshops

Product Features

Multi-gradient high-density layered glass fiber media with stable oil storage capacity, anti-saturation under long-term medium continuous load, stably maintain outlet residual oil ≤3 ppm full service cycle.

Compact deep-pleated low-resistance cylinder design, slow differential pressure rise during long full-load operation, effectively reduce power consumption of 55–90kW main unit.

Double-layer thickened stainless steel perforated anti-static inner & outer support cages, anti-corrosion and anti-pressure impact; filter media no deformation/collapse under maximum airflow, eliminate static ignition risk of oil mist.Complete fluorine rubber sealing kit included, outstanding high temperature & aging resistance, zero leakage under frequent start-stop and temperature fluctuation, prevent air-oil bypass and excessive oil carry-over faults.

Product Description

It adopts high-efficiency gradient glass fiber coalescing separation technology to capture micron-scale lubricating oil aerosol in medium-flow compressed air. Separated lubricant flows back to compressor main unit via central bottom gravity oil return tube for circulation reuse, greatly reduce oil refilling frequency and extend overall machine maintenance interval.

It fully protects downstream refrigerated dryers, adsorption dryers, precision pneumatic valves and industrial spraying equipment, lower breakdown frequency and maintenance cost of air post-processing purification system.
