Model : 7212302080123
Type : Oil Separators Filters
Replacement for : 7212302080123
It effectively removes lubricant oil mist from compressed air and limits residual oil content below 3 ppm. It prevents downstream pneumatic equipment from oil pollution, cuts oil consumption, guarantees clean compressed air output and prolongs the service life of the whole air compressor system.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
PN: 7212302080123
Type: Flange-mounted coalescing separator
Media: Imported HV Borosilicate Glass Fiber
Filtration Precision: 0.1 μm
Separation Efficiency: ≥ 99.99%
Oil Carry-over: ≤ 3 ppm
Service Life: 3500–6000 hours
Max Working Pressure: 0.7–1.3 MPa
Operating Temperature: -20°C ~ 120°C
Initial Pressure Drop: ≤ 0.02 MPa
Weight: 3.8 kg
Dimensions
OD: 195 mm
ID: 132 mm
Height: 268 mm
Features
Multi-layer high-capacity glass fiber media for thorough oil mist capture
Low initial pressure drop to lower compressor energy consumption
Anti-static steel support cage with corrosion and explosion resistance
High-temperature Viton seal ensures long-term leak-free sealing
Description
It effectively removes lubricant oil mist from compressed air and limits residual oil content below 3 ppm. It prevents downstream pneumatic equipment from oil pollution, cuts oil consumption, guarantees clean compressed air output and prolongs the service life of the whole air compressor system.
