Model : 3422014900
Type : Oil Separators Filters
Replacement for : 3422014900
It efficiently separates lubricating oil mist from compressed air and controls residual oil content under 3 ppm. It avoids oil pollution to downstream pneumatic equipment, lowers oil consumption, maintains clean compressed air supply, and prolongs the service life of the entire air compressor system
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
PN: 3422014900
Type: Flange-mounted Coalescing Separator
Media: Imported HV Borosilicate Glass Fiber
Filtration: 0.1 μm
Efficiency: ≥ 99.99%
Oil Carry-over: ≤ 3 ppm
Service Life: 3500–6000 hours
Max Pressure: 0.7–1.3 MPa
Temperature Range: -20°C ~ 120°C
Initial Pressure Drop: ≤ 0.02 MPa
Weight: 6.0 kg
Dimensions
OD: 250 mm
ID: 150 mm
Height: 340 mm
Features
High-capacity HV glass fiber media for complete capture of tiny oil mist particles
Low initial pressure drop reduces the power consumption of the compressor
Anti-static perforated steel housing with excellent corrosion and explosion resistance
Heat-resistant Viton rubber seal to maintain stable sealing performance long-term
Description
It efficiently separates lubricating oil mist from compressed air and controls residual oil content under 3 ppm. It avoids oil pollution to downstream pneumatic equipment, lowers oil consumption, maintains clean compressed air supply, and prolongs the service life of the entire air compressor system.
