Oil Separators Filters

Part No: 4940953101

Filter Media: Imported multi-layer HV borosilicate micro glass fiber composite coalescing media

Filtration Precision: ≤0.1 μm fine oil mist interception

Separation Efficiency: ≥99.999%

Residual Oil Content at Air Outlet: ≤3 ppm

Standard Service Life: 4000–6000 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20℃ ~ 120℃

Initial Pressure Drop: ≤0.02 MPa

Replacement Alarm Differential Pressure: ≥0.08 MPa

Gross Weight: ~6.2 KG

Dimensions (mm)

Flange Outer Diameter: 340

Cartridge Outer Diameter: 285

Central Inner Hole Diameter: 172

Overall Height: 520

Application Scenarios

Automobile assembly workshops, heavy machinery foundries, large injection molding plants, centralized mine air supply stations, chemical air compressor rooms, shipyard sandblasting & pipeline pressure testing, clean air production lines for pharmaceutical industry

Product Features

Multi-gradient high-density glass fiber media with large oil storage capacity, resistant to saturation under long-term full-load operation, stable residual oil content ≤3 ppm throughout the whole service cycle.

Deeply pleated low-resistance cylindrical design with slow differential pressure rise, effectively cutting power consumption of 90–110 kW main units.

Double-layer thickened stainless steel perforated anti-static inner & outer support cages, corrosion and impact resistant. Filter media will not deform or collapse under maximum airflow, eliminating static ignition risk of oil mist.Nitrile rubber gasket features outstanding high temperature and aging resistance, zero leakage under frequent startup/shutdown and dramatic temperature fluctuation to prevent air-oil bypass and excessive oil carry-over.

Product Description

It adopts high-efficiency gradient glass fiber coalescing technology to capture micron-scale lubricating oil aerosol inside compressed air. Separated lubricant flows back to airend via bottom gravity oil return tube for cyclic reuse, greatly reducing oil refilling frequency and extending overall machine maintenance interval.

It provides full protection for downstream refrigerated dryers, adsorption dryers, precision pneumatic valves and spraying equipment, lowering failure rate and maintenance cost of post-air-treatment purification systems.
