Model : DB2077
Type : Oil Separators Filters
Replacement for : DB2077
It efficiently captures and removes oil mist from compressed air, maintaining residual oil content below 3 ppm to deliver clean, dry compressed air. This separator ensures stable operation of the compressor unit and extends the service life of downstream pneumatic equipment and tools.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
PN: DB2077
Type: Flange-mounted Coalescing Separator
Media: Borosilicate Micro Glass Fiber
Filtration: 0.1 μm
Efficiency: ≥ 99.9%
Oil Carry-over: ≤ 3 ppm
Service Life: 3500–6000 hours
Max Pressure: 0.7–1.3 MPa
Temperature: -20°C ~ 120°C
Initial Pressure Drop: ≤ 0.02 MPa
Weight: 5.2 kg
Features
High-performance micro glass fiber media for superior oil mist coalescing
Low pressure drop to reduce compressor energy consumption
Anti-static steel housing with excellent corrosion and impact resistance
High-temperature resistant Viton seal for stable long-term operation
Description
It efficiently captures and removes oil mist from compressed air, maintaining residual oil content below 3 ppm to deliver clean, dry compressed air. This separator ensures stable operation of the compressor unit and extends the service life of downstream pneumatic equipment and tools.
