Coalescing Filters

Key Product Features

Double‑layer composite adsorption media

Front 0.01μm borosilicate microfiber interception layer traps residual micro oil mist and fine solid particles, preventing liquid contaminants from soaking the carbon bed and shortening adsorption life. The thick wrapped high‑specific‑area activated carbon cloth core fully adsorbs gaseous oil vapor, hydrocarbon organics and peculiar odors that coalescing filters cannot eliminate. Internal anti‑carbon‑dust isolation barrier stops carbon powder from entering downstream pneumatic pipelines.

Anti‑corrosion fully sealed all‑metal cartridge

316 stainless steel inner support tube + perforated stainless steel outer protective mesh; glass‑filled nylon twist‑lock end caps integrated with NBR nitrile sealing gasket. Internal epoxy anti‑rust coating delivers excellent resistance to compressor lubricant, condensed water and mild industrial chemicals, eliminating air bypass leakage completely.

Low pressure drop energy‑saving radial flow design

Uniform carbon cloth wrapping and evenly distributed pleated pre‑filter maximize effective adsorption area, maintaining ultra‑low initial pressure loss during long‑term continuous operation, reducing air compressor power consumption and factory overall air supply costs. Optimized inside‑out airflow avoids turbulence and rapid pressure rise after thousands of running hours.

Application Industries

Pharmaceutical sterile workshops, food & beverage aseptic filling production lines

Semiconductor wafer manufacturing, precision electronic assembly, optical lens processing

Medical & dental pneumatic equipment, laboratory ultra‑high‑purity gas supply

High‑gloss automotive clear coat spraying, aerospace precision part surface treatment, breathing air systems

Brief Overview

It combines microfiber pre‑filtration and high‑performance activated carbon cloth adsorption technology as the final purification barrier of the air treatment system. Operating stably within 1.5°C~66°C under maximum 16 bar pressure, it supplies odor‑free, oil‑vapor‑free ultra‑clean compressed air for high‑standard precision industrial production requiring strict air cleanliness control.
