Coalescing Filters

Main Features

High-efficiency coalescing filtration medium

Multi-layer gradient borosilicate glass fiber captures 0.01 μm tiny oil mist and fine dust particles, oil mist separation efficiency ≥99.99%, residual oil content of outlet air ≤0.01 ppm. The built-in hydrophobic drainage layer accelerates condensed oil and water to flow down, effectively preventing liquid secondary atomization.

Sturdy sealed structure

Double-layer stainless steel perforated support mesh avoids medium collapse under long-term airflow impact. Integrated EPDM rubber gaskets at both ends realize full sealing to prevent unfiltered air bypass leakage. Reinforced plastic end caps resist vibration for 24-hour continuous industrial operation.

Energy-saving stable performance

Low initial pressure drop reduces air compressor power consumption. Standard service life reaches 2000 running hours, replace the filter element when differential pressure rises to 0.05 MPa. Stable operation at 1°C~80°C, maximum working pressure 16 bar.

Simple maintenance

Standard cylindrical plug-in design for quick disassembly without special tools. Disposable filter, cannot be cleaned and reused.

Main Applications

Suitable for high-gloss painting, laser cutting, precision electronic assembly, pharmaceutical production and food packaging industries. Its core function is to remove micro oil mist and fine moisture in compressed air, greatly reduce pollution load of rear activated carbon filter, and protect downstream precision production equipment from oil contamination.
