Coalescing Filters

Part No: 88344254

Filtration Rating: 1 μm, residual oil content ≤0.1 mg/m³, optimized for high‑dust working conditions

Max Working Pressure: 16 bar

Operating Temperature: ‑20℃ ~ +65℃

Dimension: Φ72 mm, Length 510 mm, bayonet mounting with top handle, Weight 1.12 kg

Filter Media: Reinforced gradient multi‑layer glass‑fiber media, reinforced plastic support cage, rubber sealing gaskets

Recommended Service Life: 8000 working hours or 1 year. Replace when pressure difference reaches 0.08 bar. Shorten service interval under heavy‑dust conditions.

Main Features

Bayonet quick‑install design with top handle for tool‑free fast field replacement.

Thickened gradient glass‑fiber media with high dust‑holding capacity. Traps solid particulates, condensate and liquid oil mist for dusty compressed‑air systems.

Rigid reinforced plastic cage resists airflow impact and prevents filter media deformation for continuous‑duty operation.

Optimized media layout delivers low initial pressure drop to reduce system energy consumption. Good resistance to condensate and aging.

Integrated rubber end seals eliminate bypass airflow and guarantee full filtration efficiency.

Serves as primary pre‑filtration to protect downstream HE‑grade fine elements and extend downstream filter service life.

Application Industries

Screw compressor post‑treatment systems, mining, construction sites, general manufacturing, spray painting, food‑processing and electronics industries. Performs primary air purification for high‑dust working environments.

Product Summary

High dirt‑holding capacity suits dusty conditions. It performs pre‑purification, intercepts solid contaminants and liquid oil‑water, and safeguards downstream fine‑filtration equipment.
