TGA6108 Air Filter

Model : TGA6108

Type : Air Filters

Replacement for : TGA6108

Height : 900 mm

TGA6108 is a heavy-duty intake air filter element produced by TG FILTRI, designed for screw air compressors and industrial engines. It adopts high-density pleated filter media with large dust holding capacity and low initial resistance. The metal inner and outer frames provide structural support to

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

Part No: TGA6108

Product Name: Air Filter Element

Dimensions

Outer Diameter: 330 mm

Inner Diameter: 220 mm

Height: 900 mm

Weight: 2.6 kg

Specifications & Features

Filter Media: High-efficiency composite filter paper

Filtration Accuracy: 5 μm

Filtration Efficiency: ≥99.3%

Initial Pressure Drop: ≤0.02 MPa

End Cap: PU rubber, anti-aging and leak-proof

Structure: Double metal mesh support

Operating Temperature: -10°C to +85°C

Service Life: 2000–2500 hours

Quality Standard: ISO 9001

Function

Filters dust, sand, moisture and fine contaminants from intake air. Protects rotors, bearings and other precision parts from wear. Reduces lubricant contamination and extends the service life of oil filters, separators and oil. Maintains stable airflow and pressure for continuous efficient operation.
