1631043590 Air Filter

Model : 1631043590

Type : Air Filters

Replacement for : 1631043590

Height : 500 mm

It adopts high-purity imported wood pulp filter paper with dense pleats, featuring large dust holding capacity and low initial airflow resistance. The double-layer metal mesh provides sturdy support to prevent deformation. High-quality PU rubber end caps deliver excellent airtight performance to avo

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

Part No: 1631043590

Product Name: Air Filter Element

Dimensions

Outer Diameter: 240 mm

Inner Diameter: 150 mm

Height: 500 mm

Weight: 2.0 kg

Specifications & Features

Filter Media: Imported wood pulp filter paper

Filtration Accuracy: 5 μm

Filtration Efficiency: ≥99.5%

Initial Pressure Drop: ≤0.018 MPa

End Cap: PU rubber, leak-proof and anti-aging

Structure: Double metal mesh support, anti-deformation

Operating Temperature: -10°C to +85°C

Service Life: 2000–2500 hours under normal working conditions

Quality Standard: ISO 9001 certified production

Function

It filters out dust, sand particles, moisture and fine oil mist from intake air, and protects precision parts such as rotors and bearings against abrasion. It slows down lubricant deterioration and prolongs the service life of oil filters, oil separators and lubricating oil. It also maintains stable airflow and pressure to ensure the compressor operates efficiently and continuously.
