Air Filters

Part Number: 2901300102

Filtration Performance: Captures solid particles ≥1 μm, residual liquid oil mist ≤1 ppm

Standard Service Life: 5,000 working hours

Max Operating Pressure: 1.6 MPa

Operating Temperature Range: 2℃ ~ 65℃

Initial Pressure Drop: ≤0.008 MPa

Replacement Alarm Differential Pressure: ≥0.05 MPa

Application Scenarios

Small workshop pneumatic tools, mini laser cutting equipment, small spray booths, general mechanical processing, pre-protection for refrigerated air dryers, small electronic lab air supply, light-duty food packaging equipment

Product Features

Outer hydrophobic foam sleeve prevents separated water and oil from re-entraining into airflow, greatly improving gas-liquid separation efficiency. High dirt-holding gradient glass fiber media intercepts most coarse pollutants to slow clogging of downstream precision filters.

Ultra-low initial pressure drop deep-pleated design minimizes long-term energy loss and power consumption of small air compressors.

Epoxy sealed composite end caps + anti-corrosion plastic inner support frame, excellent shock resistance; filter media will not deform under continuous low-flow dusty airflow impact.

Integrated double EPDM rubber top O-ring sealing structure, resistant to high temperature, synthetic compressor oil and aging, completely eliminate pipeline air leakage risks.

Standard plug-in quick-install design for tool-free replacement, greatly shortening maintenance downtime

Product Description.

It removes large-particle rust, sand dust, bulk condensed water and coarse oil droplets from raw compressed air, effectively prolonging the service life of secondary coalescing, superfine and activated carbon filters, lowering overall maintenance frequency and cost of the whole small air supply system.
