Air Filters

Part Number: 6CU15-060

Filtration Performance:

Solid particles capture ≥0.01 μm

Residual liquid oil mist ≤0.008 ppm

Standard Service Life: 4,000 working hours; shorten to 2,000 hours under heavy oil mist, high humidity & spray booth environments

Max Operating Pressure: 1.6 MPa

Continuous Operating Temperature: 2℃ ~ 120℃

Initial Pressure Drop: ≤0.012 MPa

Replacement Alarm Differential Pressure: ≥0.06 MPa

Overall Dimensions:

Outer Diameter: 56.5 mm

Inner Connection Diameter: 31.5 mm

Total Height: 152.4 mm

Application Scenarios

Automotive high-gloss clear coat spraying, electronic & semiconductor small cleanroom production, precision medical testing equipment air supply, small lithium battery production lines, optical lens polishing, food sterile packaging, laboratory high-precision analytical instruments

Product Features

Multi-gradient borosilicate microglass multi-stage coalescing structure captures 99.999% of 0.01μm oil aerosols, stably controlling outlet residual oil below 0.008 ppm; outer hydrophobic foam layer automatically drains separated water and oil to avoid secondary re-entrainment into airflow, maintaining consistent long-term filtration efficiency.

Compact deep-pleated low-resistance media design keeps stable low pressure drop throughout full service cycle, effectively cutting extra power consumption of small air compressors.

Rigid full urethane sealed end caps + corrosion-resistant plastic inner retainer cage, excellent anti-vibration performance; filter media will not collapse under continuous low-medium airflow impact.

Product Description

Conventional medium-grade coalescing filters only control residual oil above 0.02 ppm, while this CU6 ultra-precision compact filter further intercepts penetrating micro oil aerosols, lowering outlet liquid residual oil to 0.008 ppm. It provides ultra-clean compressed air for small-space high-demand precision manufacturing processes, and greatly extends the service life of downstream high-precision QU filter to reduce overall air system maintenance cost.
