1C230222-01 Air Compressor Filter

Model : 1C230222-01

Type : Air Filters

Replacement for : 1C230222-01

It adopts multi-layer imported superfine glass fiber composite filter media and thickened anti-rust carbon steel support frame with integrated epoxy resin sealing technology. The air flows from outside to inside to capture suspended oil mist in compressed air, recycle lubricating oil for reuse, and

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

Part Number: 1C230222-01

Max Working Temperature: ≤120℃

Standard Service Life: 3500–6000 Working Hours

Initial Pressure Drop: ≤0.02MPa

Outlet Residual Oil Content: ≤3PPM

Application Range

Specially matched with Ingersoll Rand screw air compressors, widely used in air source purification and air-oil separation systems of machinery processing, automobile manufacturing, chemical industry, power plants, metallurgy, textile, food & pharmaceutical, refrigeration and other industries.

Key Product Features

Outstanding separation accuracy, residual oil content of outlet air ≤3PPM with high filtration efficiency, suitable for precision industrial gas supply scenarios.

Folded structure greatly expands filtration area, featuring low air resistance and tiny initial pressure drop to effectively reduce compressor energy consumption.

Gradient layered filter media owns strong dirt holding capacity, standard service life reaches 3500–6000 working hours to cut frequent replacement cost.

High temperature resistant material with good compatibility with compressor oil, not easy to aging or cracking under high temperature and pressure conditions.

Integral glue filling sealing without leakage, pressure-resistant non-deformable frame, explosion-proof and durable, easy to install and replace.

Block oil contaminants to protect rear pipelines, cylinders, pneumatic valves and precision instruments, lowering overall equipment maintenance frequency.
