Air Filters

Model: 005099-001

Core Technical Specifications

Separation Precision: 0.01 μm submicron lubricant oil mist

Residual Oil in Outlet Compressed Air: ≤3 ppm

Separation Efficiency: 99.99%

Filter Media: Multi-layer gradient HV borosilicate glass fiber composite, anti-static, high temperature resistant, anti-oil saturation

Continuous Operating Temperature: ≤110℃

Standard Service Life: 4,000–6,000 operating hours; replace immediately when differential pressure exceeds 0.8 bar

Key Product Advantages

Two-Stage Gradient Coalescence to Cut Oil Consumption

Multi-layer gradient glass fiber captures ultra-fine oil mist generated by high-flow screw compression. Agglomerated liquid lubricant oil flows back to oil tank through central return tube, greatly reducing oil consumption and stabilizing downstream compressed air cleanliness.

Low Initial Differential Pressure for Energy Saving

Oversized deep-pleated filtration area optimizes large-flow internal oil-gas flow channels, maintains stable low pressure drop under 24/7 full-load continuous operation, avoids increased motor load and extra power consumption caused by clogged separator core.

Ultra-Large Oil & Sludge Holding Capacity

Thick multi-gradient fiber matrix stores massive coalesced lubricant oil, carbon sludge and metal wear debris, effectively resisting blockage from high-temperature aging oil, suitable for mining, quarry and heavy industrial long-cycle operation.

Heavy-Duty Anti-Corrosion Reinforced Structure

Thick galvanized steel protective mesh and high-temperature composite gasket withstand long-term high-temperature oil-gas mixed environment; effectively prevents medium rupture and fiber shedding to avoid secondary oil contamination of pipeline precision filters and terminal mining equipment.

Working Principle

High-temperature high-pressure oil-gas mixture discharged from screw airend penetrates the glass fiber medium from outside to inside of separator core. Submicron oil mist particles collide and aggregate into large liquid oil droplets on fiber surface. Oil sinks to the bottom of separator by gravity and flows back to compressor lubricant tank via central return pipe; low-oil clean compressed air flows out to post-processing precision filter system.

Application & Industries

Widely applied in mining quarries, stone processing plants, tunnel construction sites, large centralized factory compressed air supply stations, heavy machinery manufacturing and large automotive spraying workshops.
