Model : P538611
Type : Oil Separators Filters
Replacement for : P538611
Height : 342 mm
It removes oil mist to ≤3ppm, reduces oil consumption, and protects downstream pneumatic equipment.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
PN: P538611
Type: Vertical Flange Coalescing Separator
Media: High-efficiency Borosilicate Glass Fiber
Filtration: 0.1 μm
Efficiency: ≥99.99%
Oil Carry-over: ≤3 ppm
Service Life: 4000–6000 hours
Max Pressure: 1.0 MPa
Temperature: -20°C ~ 120°C
Dimensions:
Flange OD: 298 mm
OD: 222 mm
ID: 149 mm
Height: 342 mm
Weight: 4.4 kg
Features
Ultra-fine glass fiber media, high coalescing efficiency
Low pressure drop
Heavy-duty steel construction, corrosion-resistant
Flange mount, direct replacement
Long life, stable for heavy-duty compressors
Description
It removes oil mist to ≤3ppm, reduces oil consumption, and protects downstream pneumatic equipment.
