Oil Separators Filters

Part No: LE33001X

Filter Medium: Multi-layer borosilicate microfiber glass fiber coalescing media

Residual oil content: ≤3 ppm

Service life: 4000–6000 working hours

Max operating temperature: 110℃

Rated working pressure: 16 bar

Sealing material: High-temperature fluororubber composite gasket

Dimension: Outer Diameter 300mm, Flange Diameter 400mm, Height 350mm

Main Features

Standard circular flange integrated structure, accurate mounting hole layout, stable installation and convenient maintenance

Multi-stage gradient high-efficiency coalescing filter material, excellent interception performance for submicron oil mist particles

Reinforced inner & outer perforated metal support cage, anti-deformation under long-term high airflow impact

High temperature resistant flat sealing gasket, effectively prevent air bypass and continuous decline of separation efficiency

Optimized uniform pleating layout, large effective filtration area, balance airflow distribution and extend service cycle

Application Industry

Widely used in machinery manufacturing, automotive processing, electronics, food, pharmaceutical, packaging and other industrial compressed air stations.

Brief Summary

It separates lubricating oil mist from compressed air, improves outlet compressed air cleanliness and recycles lubricant oil to lower compressor oil consumption.
