Oil Separators Filters

Core Technical Specifications

Filtration Grade: Primary 0.1μm high-efficiency spin-on coalescing separator for medium-large flow screw compressors

Absolute Separation Precision: 0.1 μm submicron oil mist capture

Max Continuous Working Pressure: 1.0 MPa

Working Temperature Range: -10°C ~ +110°C

Compatible Lubricants: Sullair / IR / Drilltech mineral & fully synthetic compressor coolant oil

Standard Replacement Cycle

Stable low-dust factory: 4,000–7,000 operating hours or 12 months

Construction/mining mobile equipment, heavy dust 24h operation: 2,800–4,500 hours

Mandatory Replacement Trigger: Differential pressure ΔP ≥ 0.08 MPa or visible oil carryover at air outlet

Differential Pressure Thresholds

Initial pressure drop of new element: ≤0.02 MPa

Alarm replacement differential pressure: ≥0.08 MPa

Structural Construction Features

Double-layer perforated galvanized steel cages, anti-vibration & anti-deformation for mobile compressor working conditions

Built-in central micro oil return pipeline inside cartridge, automatically recovers separated lubricant back to oil tank

Integrated heavy-duty metal spin-on thread base, good sealing, resistant to vibration leakage on mobile machines

Static conductive fiber layer eliminates static discharge hidden danger in oil-air mixed pipeline

Key Product Advantages

Extra large deep-pleated filter media with ultra-high dirt holding capacity

Super tall cartridge structure greatly expands filtration area, can absorb massive oil sludge, construction dust and carbon deposits; differential pressure rises slowly during whole service cycle, effectively reducing extra power consumption of the host.

Built-in independent oil return channel, stable low oil carryover performance

Coalesced liquid oil flows back to oil tank through internal central tube, avoids secondary re-entrainment of oil mist caused by high-speed airflow, keeps exhaust residual oil below 3 ppm long-term, reduces compressor oil consumption significantly.

Vibration-resistant spin-on structure, suitable for outdoor mobile equipment

Thickened metal thread base and fully welded inner/outer cage structure, adapts to bumping and vibration during construction site transportation and operation, prevents media deformation and oil leakage failure.

Working Principle

Mixed high-temperature oil-air gas from compressor host enters the outer perforated cage of spin-on separator, large oil droplets are intercepted and initially settled on the outer drainage fleece.

Remaining 0.1μm submicron oil mist penetrates multi-layer gradient glass fiber media; tiny oil particles collide, aggregate and coalesce into continuous liquid oil film.

Coalesced lubricant flows downward along the inner central oil return tube and returns to the bottom oil storage tank for circulation reuse.

Clean compressed air with residual oil ≤3 ppm flows out from the top air outlet to post-processing filter, dryer and production pneumatic equipment.

The element cannot be cleaned or reused. After media is saturated with sludge and dust, differential pressure surges and separation efficiency fails, must replace the whole spin-on cartridge.

Application Scope

Road construction drilling, mine blasting, municipal engineering sandblasting, general mechanical processing, metal welding workshops, medium plastic injection molding pneumatic equipment, temporary factory air supply.
