Oil Separators Filters

Part No: K320000003

Type: Spin-on threaded built-in coalescing separator cartridge

Filter Media: Imported HV Borosilicate Micro Glass Fiber composite media

Filtration Precision: 0.1 μm

Separation Efficiency: ≥ 99.99%

Residual Oil Carry-over: ≤ 3 ppm

Service Life: 4000–4500 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20°C ~ 120°C

Initial Pressure Drop: ≤ 0.02 MPa

Net Weight: ~1.2 kg

Dimensions

Outer Diameter (OD): 135 mm

Overall Height: 205 mm

Product Features

Multi-layer HV glass fiber composite media with compact large filtration area, strong oil mist holding capacity, stable separation efficiency under continuous light & medium load operation.

Optimized uniform fiber stacking low-resistance design keeps ultra-low initial pressure drop, slows differential pressure growth and effectively reduces power consumption of small screw compressors.

Integral thickened aluminum sealed outer barrel + anti-static inner support mesh, good shock and vibration resistance, prevents filter element deformation and oil bypass under fluctuating working pressure.

High-temperature resistant nitrile rubber integrated sealing ring, reliable sealing against drastic temperature swings to eliminate oil leakage and excessive oil residue in outlet compressed air.

Product Description

It adopts high-efficiency glass fiber coalescing technology to capture ultra-fine lubricant mist suspended in compressed air, controlling residual oil content of outlet air below 3 ppm.

It fully protects downstream air dryers, small precision pneumatic tools and short-distance air pipelines, significantly cuts lubricating oil consumption, supplies stable clean compressed air, and extends the overall service life of the compressor unit and matched post-processing accessories.
