Oil Separators Filters

Part No: 9127518505

Type: External vertical cylindrical spin-on air/oil separator cartridge

Filter Media: Imported HV Borosilicate Micro Glass Fiber composite coalescing media

Filtration Precision: ≤0.1 μm

Separation Efficiency: ≥99.99%

Residual Oil Carry-over: ≤3 ppm

Service Life: 3000–4500 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20℃ ~ 120℃

Initial Pressure Drop: ≤0.02 MPa

Net Weight: 3.18 kg

Dimensions (mm)

Overall Outer Diameter: 240

Total Height: 190

Application Scenarios

Auto repair garages, precision machining workshops, plastic injection molding, electronic component assembly lines, packaging factories, small & medium factory centralized compressed air supply stations

Product Features

Multi-gradient high-density borosilicate glass fiber media with stable oil mist holding capacity, resisting oil saturation under long-term light & medium continuous load and maintaining consistent separation efficiency throughout full service cycle.

Uniform deep-pleated low-resistance internal structure with ultra-low initial pressure loss; differential pressure rises moderately during full-load operation to effectively cut power consumption of Mitsuiseiki medium-small screw compressors.

Integral thickened anti-corrosion steel shell with built-in double-layer perforated anti-static support mesh, resistant to pressure fluctuation and mechanical shock; eliminates static ignition risks in oil mist environment.

Standard spin-on threaded interface with one-piece integrated high-temperature rubber gasket, supporting quick direct screw installation. Stable sealing performance under drastic day-night temperature changes to avoid oil bypass and excessive oil carryover in compressed air.

Product Description

It adopts high-efficiency gradient glass fiber coalescing technology to capture micron-scale lubricant aerosol mixed in compressed air, limiting residual oil content of outlet air below 3 ppm. Separated lubricant flows back to the compressor main unit through the built-in bottom return passage for circulation, greatly reducing lube oil consumption.

It provides comprehensive protection for downstream refrigerated dryers, precision pneumatic tools and long-distance air pipelines, extending maintenance interval and overall service life of the whole small-medium compressor unit and supporting post-processing purification equipment.
