Oil Separators Filters

Part No: 6.3559.1

Filter Media: Imported HV multi-layer borosilicate micro glass fiber composite media

Separation Efficiency: ≥99.999%

Standard Service Life: 3500–6000 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20℃ ~ 120℃

Initial Pressure Drop: ≤0.02 MPa

Replacement Alarm Differential Pressure: ≥0.08 MPa

Dimensions (mm)

Flange Outer Diameter: 360mm

Cartridge Outer Diameter: 340mm

Central Inner Hole Diameter: 255mm

Overall Height: 460mm

Application Scenarios

Auto parts processing, heavy machinery machining, medium-large injection molding workshops, factory central compressed air stations, mining pneumatic equipment, ship auxiliary air supply, food & pharmaceutical production lines

Product Features

Multi-gradient high-density glass fiber media with large oil mist storage capacity, anti-saturation under long medium-heavy continuous loads, stably controls residual oil ≤3 ppm throughout full service cycle.

Deep uniform pleated low-resistance cylinder, slow differential pressure rise during long full-load running, effectively reduces power consumption of 132–185kW main unit.

Double-layer perforated galvanized anti-static inner & outer support cages, anti-corrosion & anti-pressure surge; filter media no deformation or collapse under high airflow, eliminate static ignition risk of oil mist.

Product Description

It adopts high-efficiency gradient glass fiber coalescing separation technology to capture micron-level lubricant oil aerosol mixed in high-flow compressed air. Separated lubricant flows back to the main unit through the central bottom gravity oil return tube for recycling, greatly reduces lubricating oil consumption and extends overall machine maintenance interval.

It provides full protection for downstream refrigerated dryers, adsorption dryers, heavy-duty precision pneumatic valves and spraying equipment, lowers breakdown frequency and maintenance cost of air post-processing purification system.
