Oil Separators Filters

Key Product Features

High-capacity two-stage coalescing glass fiber media

Three-dimensional deep pleated borosilicate microfiber forms dual coalescence structure. Tiny suspended oil droplets collide, aggregate into large oil beads and flow back to compressor oil tank by gravity. Effectively reduce compressor lubricant consumption and prevent oil contamination to downstream pipeline precision filters.

Heavy-duty anti-corrosion spin-on housing

Thickened steel shell withstands long-term high temperature and pressure inside air compressor system. Epoxy anti-rust coating avoids rust and corrosion in humid industrial workshops, extending the whole service life of separator.

Tool-free screw-in quick replacement design

Spin-on threaded connection, operators can twist and replace directly without special disassembly tools, greatly cutting equipment maintenance downtime. Integrated built-in sealing ring eliminates medium leakage risks at joint surface.

Stable low differential pressure operation

Optimized uniform pleating layout evenly distributes compressed air flow, maintains ultra-stable low airflow resistance throughout the whole service cycle, avoids excessive pressure loss which causes extra power consumption of screw host and saves factory electricity cost.

Application Industries

Automotive high-gloss clear coat spraying, furniture & hardware coating workshops

Precision electronic assembly, optical lens processing production lines

Food & beverage aseptic filling, pharmaceutical sterile workshops

Central factory air compressor stations, nitrogen generator supporting gas purification

General machinery automatic pneumatic assembly production lines, textile & packaging equipment

Brief Overview

It serves as core secondary separation component to remove residual lubricating oil aerosol from compressed air, lower compressor oil consumption and fully protect downstream precision filter consumables. Stable performance within -5℃~110℃ and maximum 22 bar burst pressure, it is essential routine maintenance spare part for Ingersoll Rand industrial screw air compressors.
