Oil Separators Filters

Part No: 3582228

Type: Spin-on threaded coalescing air/oil separator cartridge

Filter Media: Imported HV Borosilicate Micro Glass Fiber composite media

Filtration Precision: 0.1 μm

Separation Efficiency: ≥ 99.99%

Residual Oil Carry-over: ≤ 3 ppm

Service Life: 3000–4500 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20℃ ~ 120℃

Initial Pressure Drop: ≤ 0.02 MPa

Net Weight: 2.27 kg

Dimensions

Cartridge Outer Diameter: 172 mm

Central Thread Port Diameter: M80 standard spin-on interface

Overall Height: 276 mm

Application Scenarios

Open-pit mining, tunnel excavation, rock drilling, road construction, pipeline engineering, outdoor heavy-duty high-dust & strong vibration operation sites

Product Features

Multi-layer dense HV ultra-fine borosilicate glass fiber media with large oil mist storage capacity, stable separation performance under long-term bumpy outdoor harsh mining working conditions.

Optimized evenly pleated low-resistance layout with ultra-low initial pressure drop, slow differential pressure rise during continuous operation to effectively reduce diesel fuel consumption of mobile compressors.

Integrated heavy-duty metal shell with anti-static inner support mesh, impact resistant, anti-corrosion and no deformation under severe vibration and fluctuating system pressure.

One-piece built-in high-temperature resistant sealing gasket, reliable leak-proof performance under dramatic day-night temperature changes to eliminate oil bypass and over-limit residual oil in outlet compressed air.

Product Description

It adopts advanced HV borosilicate glass fiber coalescing technology to capture ultra-fine lubricant aerosol suspended in compressed air, controlling residual oil content of outlet compressed air below 3 ppm.It provides full protection for downstream air dryers, pneumatic rock drills, sandblasting equipment and long-distance air transmission pipelines, greatly extends lubricant replacement cycle, supplies ultra-clean stable compressed air, and prolongs the full service life of the whole mobile compressor unit and all supporting post-processing accessories.
