Oil Separators Filters

Part No: 1018730004

Type: External spin-on threaded air/oil separator cartridge

Filter Media: Imported HV Borosilicate Micro Glass Fiber composite coalescing media

Filtration Precision: ≤0.1 μm

Separation Efficiency: ≥99.99%

Residual Oil Carry-over: ≤3 ppm

Service Life: 3000–4500 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20℃ ~ 120℃

Initial Pressure Drop: ≤0.02 MPa

Net Weight: 1.35 kg

Seal: Integrated high-temperature nitrile rubber bottom gasket, no extra seal required

Dimensions (mm)

Outer Diameter: 130

Total Height: 278

Application Scenarios

Auto repair garages, small precision machining workshops, plastic injection molding, electronic component assembly, packaging small factories, laboratory low-oil compressed air supply stations

Product Features

Multi-gradient high-density micro glass fiber media with stable oil mist holding capacity, resisting oil saturation under long-term light & medium continuous load, maintaining ultra-low residual oil output throughout full service cycle.

Uniform deep-pleated low-resistance internal structure with ultra-low initial pressure loss; differential pressure rises moderately during full-load operation to effectively cut power consumption of small European screw compressors.

Thickened anti-corrosion steel outer shell with built-in double-layer perforated anti-static support mesh, shock and pressure fluctuation resistant; anti-static design eliminates static ignition risks in oil mist environment.

Standard spin-on threaded interface with one-piece integrated high-temperature rubber gasket, quick screw-on installation without additional sealing parts. Stable sealing under frequent start-stop and drastic temperature changes to avoid oil bypass and excessive oil carryover.

Product Description

It adopts high-efficiency gradient glass fiber coalescing technology to capture micron-scale lubricant aerosol mixed in compressed air, limiting outlet residual oil content below 3 ppm. Separated lubricant flows back to the compressor main unit through the built-in bottom return passage for recycling, greatly lowering lube oil consumption and extending maintenance interval.

It provides comprehensive protection for downstream refrigerated dryers, precision pneumatic tools and short-distance air pipelines, reducing maintenance cost of post-processing purification equipment.
