Oil Separators Filters

Part No: 6.1931.1

Filter Media: Imported HV Borosilicate Micro Glass Fiber composite coalescing media

Filtration Precision: ≤0.1 μm

Separation Efficiency: ≥99.99%

Residual Oil Carry-over: ≤3 ppm

Service Life: 3500–6000 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20℃ ~ 120℃

Initial Pressure Drop: ≤0.02 MPa

Net Weight: 1.6 kg

Dimensions (mm)

Flange Outer Diameter: 160mm

Cartridge Outer Diameter: 140mm

Central Inner Hole Diameter: 90mm

Overall Height: 200mm

Application Scenarios

Auto repair shops, small precision machining workshops, plastic injection molding, electronic assembly lines, laboratory low-oil compressed air supply, small packaging factories

Product Features

Multi-gradient high-density micro glass fiber media with stable oil mist holding capacity, avoids oil saturation under long-term light & medium continuous load, maintains ultra-low residual oil output throughout full service cycle.

Double-layer fully perforated galvanized anti-static inner & outer support cages, anti-corrosion and shock resistant; anti-static design eliminates static ignition risks in oil mist environment.

High-temperature nitrile gasket ensures stable sealing under frequent start-stop and drastic temperature changes to prevent oil bypass.

Product Description

It adopts high-efficiency gradient glass fiber coalescing technology to capture micron-scale lubricant aerosol mixed in compressed air, limiting outlet residual oil content below 3 ppm. Separated lubricant flows back to the compressor main unit via central scavenge tube for recycling, greatly lowering lube oil consumption.

It provides comprehensive protection for downstream refrigerated dryers, precision pneumatic tools, measuring instruments and short-distance air pipelines, extending maintenance interval and overall service life of small compressor units and post-processing purification equipment
