Oil Filters

Part No.: 39796974

Dimension: OD 114mm, Height 235mm, Thread:1-1/8"-16 UN

Filter Media: Composite cellulose mixed with fine glass fiber

Filtration precision:10μm, filtration efficiency ≥99%

Standard service life: 2000 working hours, up to 4000 hours under clean operating environment

Features

Deep-pleated composite filter medium with excellent dirt holding capacity to capture metal wear debris, carbon sludge and rust contaminants effectively.

Built-in anti-drainback valve retains oil inside filter after shutdown to avoid dry-start abrasion; bypass valve opens at 1.3bar differential pressure to guarantee continuous oil flow and prevent overheat shutdown.

Thick electrophoretic anti-rust steel housing with high-temperature resistant NBR gasket, reliable sealing under continuous vibration and unstable oil pressure.

Description

It is an essential consumable of compressor lubrication system, mounted on main oil pipeline to purify circulating lubricant, protect airend and bearings, stabilize operating temperature, extend oil service cycle and reduce unexpected maintenance cost.
