Model : 1089062408
Type : Compressor Solenoid Valves
Replacement for : 1089062408
It is a key load‑unload control spare part. It switches compressed‑air circuit by coil energizing and de‑energizing to realize compressor loading, unloading and blow‑off functions.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
Main Features
Brass Valve Body: High‑strength brass alloy body, good oil‑corrosion resistance, adapts to severe compressor working conditions.
Pilot‑assisted Diaphragm Structure: Large flow capacity, stable switching performance, anti‑clogging against oil‑aerosol impurities in compressed air, suitable for frequent cyclic operation.
Industrial‑grade DC24V Coil: 8W power consumption, fast response, excellent shock‑proof and dust‑proof performance for continuous industrial workshop operation.
Applications
Controls intake actuator to complete automatic load‑unload cycles, performs blow‑down venting during unloading and shutdown. Releases residual pressure inside separator tank, prevents heavy‑load motor startup and protects compressor main unit.
Working Principle
De‑energized state: Valve remains open, air passage connected.
Energized state: Electromagnetic force drives pilot diaphragm to close main valve port, air circuit cut‑off.
De‑energized: Spring resets diaphragm, valve opens, one control cycle finished.
