Air Filters

Part No: P119372

Product Name: Air Filter Element

Description

It acts as a secondary protection behind the primary air filter. It blocks contaminants from entering the equipment if the primary filter gets damaged or improperly installed, and prevents dirty air backflow during filter replacement. It will quickly clog to alert operators of abnormal pollution.

Specifications

Filter Type: Cylindrical inner safety filter

Filter Media: High-density long fiber paper

Filtration Accuracy: 5–10 μm

Standard: ISO 5011

Outer Diameter:  185 mm

Inner Diameter:  157.4 mm

Height:  449.6 mm

Structure: Metal end caps with rubber sealing base

Operating Temperature: -40°C to +82°C

Net Weight: approx. 1.61 kg

Function

Provides reliable backup protection when the primary filter fails

Isolates dust during primary filter replacement

Rapid clogging gives warning of excessive contamination

Protects compressor rotors, engine cylinders and turbochargers from wear

Key Features

Solid structure with excellent vibration resistance

Effective sealing to avoid unfiltered air bypass

Durable for long service in harsh working conditions
