5001865725 Air Filter

Model : 5001865725

Type : Air Filters

Replacement for : 5001865725

Height : 557 mm

It adopts high-grade multi-layer cellulose filter media with precise pleating, delivering large dust holding capacity and stable low pressure drop. The robust metal inner and outer support cages prevent media deformation under high airflow. Equipped with high-elastic polyurethane (PU) end caps for f

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

Part No: 5001865725

Product Name: Air Filter Element

Dimensions

Outer Diameter: 313 mm

Inner Diameter: 177 mm

Height: 557 mm

Weight: 4.18 kg

Specifications & Features

Filter Media: High-efficiency cellulose filter paper

Filtration Accuracy: 5–10 μm

Filtration Efficiency: ≥98%

Dust Holding Capacity: Ultra-high

Initial Pressure Drop: ≤0.02 MPa

End Cap: PU rubber, leak-proof, anti-aging

Structure: Double metal mesh, anti-deformation, reinforced

Operating Temperature: -10°C to +85°C

Service Life: 2500–3500 hours

Quality Standard: ISO 9001 certified production

Function

Removes dust, sand, moisture, and fine particles from intake air. Protects engine cylinders, pistons, bearings, and other precision parts from abrasive wear. Reduces engine oil contamination, extends the service life of oil filters and lubricants. Maintains stable intake airflow and pressure, ensuring the engine runs efficiently, continuously, and reliably.
