Air Filters

Part Number: 2901300004

Filtration Performance:

Solid particle absolute retention ≥1 μm

Residual liquid oil mist ≤1 ppm

Standard Service Life: 5,000 working hours

Max Operating Pressure: 1.6 MPa

Operating Temperature Range: 2℃ ~ 65℃

Initial Pressure Drop: ≤0.008 MPa

Replacement Alarm Differential Pressure: ≥0.05 MPa

Net Weight: 158.76 g

Application Scenarios

General factory pneumatic tool air supply, mechanical processing & foundry workshops, pre-protection for refrigerated air dryers, medium-sized spray booth pretreatment, lithium battery factory auxiliary air supply, general food packaging equipment, laboratory conventional instrument gas supply

Product Features

Outer hydrophobic foam drainage sleeve automatically drains separated liquid water and oil, effectively avoiding secondary re-entrainment into airflow and improving gas-liquid separation efficiency. High dirt-holding gradient glass fiber media captures most coarse pollutants to slow clogging of downstream high-precision filter elements.

Deep-pleated ultra-low initial pressure drop design minimizes continuous energy loss and power consumption of medium-flow air compressors.

Epoxy fully sealed composite end caps + corrosion-resistant plastic inner support cage, excellent anti-vibration performance; filter media will not deform or collapse under long-term dusty airflow impact.

Product Description

It removes large-particle rust, sand dust, bulk condensed water and coarse oil droplets from raw compressed air, effectively extending the service life of secondary coalescing, superfine and activated carbon filters, lowering overall maintenance frequency and cost of the entire medium air supply system.
