Key Product Features

Dual composite adsorption & particle interception structure

Two-stage integrated design: Front borosilicate microfiber barrier fully blocks residual liquid oil mist and fine dust to avoid rapid carbon saturation. High-specific-area activated carbon thoroughly adsorbs oil vapor, VOCs and unpleasant hydrocarbon odors that coalescing filters cannot remove. Rear microfiber fleece prevents carbon powder leakage into downstream pneumatic pipelines.

Optimized flow distribution & ultra-low pressure drop

Built-in flow guide insert evenly distributes incoming compressed air to fully utilize the entire carbon bed, minimizing airflow resistance and reducing long-term power consumption of air compressors. Uniform carbon packing ensures stable adsorption efficiency throughout the whole service life.

Corrosion-resistant all-metal reinforced frame

Dual-layer 304 stainless steel support sleeves tightly lock filter media, effectively preventing media deformation and airflow bypass under continuous stable compressed air flow. Aluminum end caps and Viton seals maintain reliable leak-proof performance under fluctuating industrial temperature and pressure conditions.

Application Industries

Automotive high-gloss clear coat spraying, furniture & hardware coating workshops (silicone-free design avoids paint defects)

Precision electronic assembly, optical lens manufacturing

Pharmaceutical sterile production lines, food & beverage aseptic filling

Laboratory high-purity gas supply, medical & dental pneumatic equipment

Breathing air treatment, chemical and petrochemical processing plants

Brief Overview

Equipped with integrated microfiber pre-filter and high-capacity activated carbon media, it acts as the last purification barrier to deliver odor-free, oil-vapor-free ultra-clean compressed air. Stable performance within 1–60°C and maximum 16 bar pressure, it is the standard OEM replacement consumable for high-cleanliness industrial compressed air treatment systems.
