SAO56020 Oil Separators Filter

Model : SAO56020

Type : Oil Separators Filters

Replacement for : SAO56020

Separates lubricating oil mist from compressed air, recycles lubricant and delivers clean compressed air for general pneumatic equipment, mechanical processing, packaging and textile industries.

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

Model: SAO56020

Core Dimension Specs

Overall Height: 466 mm

Outer Diameter: 123 mm

Inner Diameter: 88 mm

Net Weight: 1.46 kg

Basic Technical Parameters

Max Working Temp: ≤120℃

Residual Oil Content: ≤3 ppm

Service Life: 3500–6000 working hours

Initial Pressure Drop: ≤0.02 MPa

Product Features

Gradient multi-layer glass fiber medium, high coalescing efficiency for oil mist separation

Low differential pressure drop, reduce air compressor power consumption

Hydrophobic & oleophobic treated filter material, large dirt & oil holding capacity

Perforated metal inner support cage, high pressure resistance, stable continuous operation

Main Uses

Separates lubricating oil mist from compressed air, recycles lubricant and delivers clean compressed air for general pneumatic equipment, mechanical processing, packaging and textile industries.
