Oil Separators Filters

Part No: OA1107

Filter Media: Multi-layer borosilicate micro glass fiber coalescing media

Separation Efficiency: ≥99.99%

Residual Oil Carry-over: ≤3 ppm

Standard Service Life: 4000–6000 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20℃ ~ 120℃

Initial Pressure Drop: ≤0.02 MPa

Replacement Alarm Differential Pressure: ≥0.08 MPa

Net Weight: 0.45 kg

Dimensions (mm)

Outer Diameter: 80

Overall Height: 95

Application Scenarios

Small auto repair shops, laboratory equipment, dental air supply, small packaging machinery, hobby workshop pneumatic tools, small precision processing equipment

Product Features

Multi-gradient compact glass fiber media with good oil mist holding capacity. It prevents oil saturation under light continuous loads and maintains stable low residual oil output throughout the whole service cycle.

Short cylindrical low-resistance structure with ultra-low initial pressure loss.

Reinforced full-perforated galvanized anti-static inner support mesh, anti-corrosion and shock-resistant. It eliminates static ignition risks inside oil mist environment, and filter media will not deform under long-term full-load running.

Matched dual nitrile O-rings provide reliable leak-free sealing under frequent start-stop and temperature fluctuation, avoiding oil bypass and excessive oil carry-over into clean air.

Product Description

It adopts compact high-efficiency gradient glass fiber coalescing technology to capture micron-scale lubricant aerosol mixed in compressed air, controlling outlet residual oil content below 3 ppm. Separated lubricant flows back to compressor main unit through built-in bottom oil return channel for recycling, effectively cutting oil consumption and extending machine maintenance cycle.

It provides effective protection for downstream small precision pneumatic valves, laboratory instruments and miniature air drying equipment, lowering failure rate and maintenance cost of post-processing purification system.
