Oil Separators Filters

Part No.: 3422013000

Type: Flange-mounted built-in coalescing separator

Filter Media: Imported HV Borosilicate Micro Glass Fiber

Filtration Precision: 0.1 μm

Separation Efficiency: ≥ 99.99%

Residual Oil Carry-over: ≤ 3 ppm

Service Life: 3500–6000 working hours

Max Working Pressure: 0.7–1.3 MPa

Operating Temperature Range: -20°C ~ 120°C

Initial Pressure Drop: ≤ 0.02 MPa

Net Weight: 3.8 kg

Dimensions

Outer Diameter (OD): 196 mm

Inner Diameter (ID): 126 mm

Overall Height: 272 mm

Product Features

Multi-layer imported HV glass fiber media with large oil storage capacity, maintaining stable separation efficiency under dusty outdoor and long-term heavy-load working conditions.

Optimized dense-pleat low-resistance design delivers ultra-low initial pressure drop, preventing excessive differential pressure rise during long-hour operation and cutting power/fuel consumption.

Double-layer fully perforated anti-static inner & outer support cages with excellent shock and pressure resistance, avoiding element collapse and deformation under bumpy construction site conditions.

Integrated high & low temperature resistant composite flange gasket prevents oil bypass leakage under drastic day-night temperature fluctuations.

Product Description

It captures ultra-fine lubricant mist in compressed air via advanced glass fiber coalescing technology and limits residual oil content in outlet air below 3 ppm.

It effectively protects downstream equipment including air dryers, pneumatic rock drills and sandblasting tools, greatly reduces lubricating oil consumption, supplies continuous clean compressed air, and extends the service life of the whole compressor unit and post-processing accessories.
