Oil Separators Filters

PN: 3002609980

Type: External Spin-on Air-Oil Separator

Media: HV/Lydall borosilicate glass fiber

Filtration: 0.1 μm

Efficiency: ≥ 99.99%

Oil Carry-over: ≤ 3 ppm

Service Life: 4000–6000 hours

Max Pressure: 1.0 MPa

Temperature: -20°C ~ 120°C

Dimensions: H265 × OD160 × ID85 mm

Weight: 3.2 kg

Application

Field: External fine oil separation for small-medium screw compressors

Features

High-efficiency coalescing glass fiber media

Low pressure drop (≤0.02 MPa), energy saving

Heavy-duty spin-on, corrosion-resistant housing

Integrated seal, leak-proof

Reduces oil consumption, protects dryers/filters

Description

Removes oil mist to ≤3ppm, ensures clean air and extends compressor life.
