2911016000 Air Oil Separator Filter

Model : 2911016000

Type : Oil Separators Filters

Replacement for : 2911016000

Adopts high-efficiency borosilicate micro glass fiber media to coalesce fine oil mist, control oil carry-over below 3PPM. Compact cylindrical structure, low pressure drop, long service life for mobile compressor maintenance.

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

Model No: 2911016000

Filter Media: Borosilicate composite micro glass fiber

Max Working Temperature: ≤120℃

Standard Service Life: 3500–6000 working hours

Outlet Residual Oil Content: ≤3PPM

Structure: Cylindrical built-in air oil separator with metal end caps

Product Features

Excellent coalescing separation performance, outlet residual oil ≤3PPM, meets industrial clean compressed air standards

Optimized cylindrical deep pleated layout expands effective filter area, strong dirt holding capacity, service life 3500–6000 working hours

Integral thickened metal end cap & built-in support frame, high structural rigidity, anti-collapse under high airflow pressure

Imported micro glass fiber media with outstanding high temperature & lubricant corrosion resistance, no fiber shedding

Smooth internal airflow channel keeps ultra-low initial pressure drop, reduces mobile compressor power consumption

Full epoxy glue integral sealing eliminates air & oil bypass leakage, matched sealing ring fits tightly with oil tank

Max working temperature up to 120℃, stable operation for all-weather outdoor construction sites

Application Scope

Mainly used for mobile air compressors on construction sites, road engineering, mining, pipeline maintenance, municipal engineering and field construction operations. Also applicable to small fixed industrial screw compressors requiring compact built-in oil separators.
