Model : 24771180
Type : Oil Separators Filters
Replacement for : 24771180
Height : 300 mm
High-density pleated media captures dust effectively. Precise dimension ensures perfect fit and good sealing. Protects machine parts, maintains steady operation and easy to install.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
Model No: 24771180
Product Name: Secondary Oil Separator Core
Features
Media: High‑efficiency borosilicate glass fiber + polyester composite
Efficiency: ≥99.9% @ 0.1 μm; residual oil ≤ 3 ppm
Initial Pressure Drop: ≤ 0.2 bar
Structure: Compact spin‑on cartridge, metal housing, rubber gasket seal
Max Working Pressure: 1.0 MPa
Max Working Temperature: 120°C
Service Life: 4,000–6,000 hours
Dimensions
Outer Diameter: 132 mm
Height: 300 mm
Connection: Threaded interface
Function
Separates fine oil mist from compressed air
Reduces residual oil content to ≤3 ppm
Protects downstream equipment and ensures clean air supply
Extends service life of compressor and components
