1614905400 Oil Separators Filter

Model : 1614905400

Type : Oil Separators Filters

Replacement for : 1614905400

It efficiently removes fine oil mist from compressed air, lowers oil consumption, and protects downstream pneumatic equipment in general industrial applications.

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

PN: 1614905400

Type: Flange-mounted coalescing separator

Media: HV borosilicate glass fiber

Filtration precision: ≤ 0.1 μm

Separation efficiency: ≥ 99.99%

Oil carry-over: ≤ 3 ppm

Weight: 3.2 kg

Service life: 3500 – 5200 working hours

Initial pressure drop: ≤ 0.02 MPa

Max working pressure: 1.3 MPa

Working temperature: -20°C ~ 120°C

Features

Heavy-duty construction: Double metal cage, anti-collapse and corrosion resistant.

Stable performance: Consistent pressure drop throughout service life, reduces maintenance costs.

Description

It efficiently removes fine oil mist from compressed air, lowers oil consumption, and protects downstream pneumatic equipment in general industrial applications.
