Oil Separators Filters

PN: 1028850180

Type: External screw-on coalescing separator

Filtration Precision: ≤ 0.1 μm

Separation Efficiency: ≥ 99.99%

Oil Carry-over: ≤ 3 ppm

Service Life: 6000–8000 hours

Initial Pressure Drop: ≤ 0.02 MPa

Max Working Pressure: 1.6 MPa (16 bar)

Working Temperature: -20°C ~ 120°C

Dimensions: H367 × OD165 × ID110 mm

Weight:  3.8 kg

Fields: Small industrial screw compressors, workshop pneumatic systems

Features

Spin-on design, easy installation & replacement

High-efficiency glass fiber, ultra-low residual oil

Compact size, space-saving external mounting

Anti-static conductive structure, explosion-proof

Low pressure loss, energy saving

Description

Efficiently removes oil mist, reduces oil consumption, protects downstream pneumatic equipment.
