Model : 02250160-775
Type : Oil Separators Filters
Replacement for : 02250160-775
It is constructed with multi-layer HV borosilicate composite micro glass fiber, thick galvanized perforated metal support cage and integrated full epoxy seamless sealing structure with matched rubber gasket.The depth coalescing filter layers trap ultra-fine oil aerosol mixed in high-speed compressed
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
Model No: 02250160-775
Filter Type: Built-in Cylindrical Air Oil Separator
Filter Media: HV Borosilicate Composite Micro Glass Fiber
Filtration Precision: 0.1μm
Outlet Residual Oil: ≤3PPM
Separation Efficiency: ≥99.99%
Max Working Pressure: 1.0MPa
Max Working Temperature: ≤120℃
Standard Service Life: 3500–6000 Working Hours
Application Scope
Matching medium and large fixed screw compressors, widely used in machinery processing, auto spraying lines, electronics assembly, food packaging, pharmaceutical production, chemical plants, textile mills, mining and centralized air compressor stations.
Product Features
High coalescing efficiency ≥99.99%, filtration precision 0.1μm, outlet residual oil ≤3PPM, meets ISO8573-1 clean air standard
Deep pleated large-area design, strong oil and dirt holding capacity, service life 3500–6000 working hours
Double-layer galvanized metal inner support, high compression resistance, anti-collapse under long-term large airflow
High temperature & oil resistant microfiber media, no fiber shedding to avoid secondary compressed air pollution
Optimized internal flow channel keeps ultra-low initial pressure drop, cutting compressor system energy loss
Integral epoxy full sealing plus matched sealing ring, thoroughly eliminate air & oil bypass leakage
Max working temperature up to 120℃, fit standard industrial working pressure 0.7–1.0MPa
Cylindrical built-in structure, easy disassembly to shorten equipment maintenance time
