WD13145 Oil Filter

Model : WD13145

Type : Oil Filters

Replacement for : WD13145

Built-in anti-drainback valve avoids oil backflow after machine stops, ensures quick cold startup oil supply.Integrated bypass valve safeguards hydraulic system under clogged filter or cold high-viscosity oil conditions.Nitrile rubber sealing gasket resists oil corrosion and prevents leakage during

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

Model: WD13145

Type: Spin-on Lube Oil Filter

Dimensions

Outer Diameter: 136 mm

Total Height: 302 mm

Thread Size: 1 1/2-16 UN

Gasket Inner Dia: 100 mm | Gasket Outer Dia: 111 mm

Bypass Opening Pressure: 2.5 bar

Net Weight: 2.26 kg

Technical Parameters

Filter Media: High efficiency glass fiber / HV filter paper

Filtration Rating: 10~15 μm

Standard Service Life: 2000 working hours

Max Working Pressure: 20 bar

Operating Temperature: -10℃ ~ +100℃

Product Advantages

Built-in anti-drainback valve avoids oil backflow after machine stops, ensures quick cold startup oil supply.

Integrated bypass valve safeguards hydraulic system under clogged filter or cold high-viscosity oil conditions.

Nitrile rubber sealing gasket resists oil corrosion and prevents leakage during long continuous operation.

Large contaminant holding capacity with low flow resistance to lower compressor power consumption.
