Model : LB962
Type : Oil Filters
Replacement for : LB962
OEM‑grade spin‑on air‑oil separator for small‑to‑medium screw compressors. It efficiently coalesces and separates oil mist from compressed air, ensuring clean air quality and low oil carryover, protecting downstream equipment.
Part numbers marked "replacement" are not affiliated with the original manufacture.
Fluidguard is a technology-based enterprise integrating industry and trade, with strong technical strength and production capacity.
PN: LB962
Type: Spin‑on air‑oil separator
Thread: M24 × 1.5
Outer diameter: 93 mm
Height: 212 mm
Weight: 0.85 kg
Filtration precision: 0.1–0.3 μm
Efficiency: ≥99.99%
Residual oil content: ≤3 ppm
Service life: 4000–5000 hours
Max working pressure: 2.0 MPa
Initial pressure drop: ≤0.02 MPa
Seal: Viton / NBR gasket
Media: High‑efficiency HV glass fiber
Features
Sub‑micron coalescing: Removes oil mist down to 0.1 μm, residual oil ≤3 ppm.
High dirt holding capacity: Extended service life (4000–5000 h) reduces maintenance cost.
Heavy‑duty steel housing: Withstands 20 bar pressure, corrosion‑resistant.
Spin‑on design: Tool‑free installation, fast replacement, minimal downtime.
Description
OEM‑grade spin‑on air‑oil separator for small‑to‑medium screw compressors. It efficiently coalesces and separates oil mist from compressed air, ensuring clean air quality and low oil carryover, protecting downstream equipment.
