Oil Filters

The 11000889 is a heavy-duty spin-on oil filter, developed for industrial diesel engines, construction machinery, commercial vehicles and engineering equipment lubrication systems. It efficiently captures metal debris, carbon deposits, sludge and fine contaminants in engine oil. It keeps the lubrication system clean, reduces wear of internal parts, prevents oil circuit blockage, and ensures long-term stable operation of the engine.

Key Features

Equipped with high-performance multilayer composite filter media, delivering precise filtration accuracy and large dirt holding capacity to prolong service life.

Built-in anti-drain back valve avoids oil backflow after shutdown and protects the engine from dry start damage.

Internal bypass valve ensures continuous oil supply during cold start or when the filter is clogged.

Thickened all-steel shell structure features high pressure resistance and deformation resistance, suitable for severe working conditions.

High-quality nitrile rubber sealing ring offers tight fitting, aging resistance and reliable anti-leakage performance.

Standard overall size and thread design allow quick installation and direct replacement without any modification.

Technical Specifications

Part Number: 11000889

Type: Spin-on Oil Filter

Outer Diameter: 93 mm

Overall Height: 145 mm

Seal Outer Diameter: 71 mm

Seal Inner Diameter: 62 mm

Thread Size: 3/4-16 UNF

Filtration Rating: 10 μm

Filtration Efficiency: ≥ 99.5%

Bypass Valve Opening Pressure: 2.5 bar

Max Working Pressure: 2.0 MPa

Service Life: 2000–3000 operating hours

Application:Suitable for construction machinery, agricultural equipment, heavy-duty trucks, industrial diesel engines and generator sets with matching mounting dimensions.
