Hoses, Piping & Tubes

Part No: 85575173

Hose Body Material: High‑temperature resistant synthetic rubber, multi‑layer steel wire braid reinforcement, black outer protective cover

Fitting Material: Carbon steel galvanized crimped integrated assembly, double 90° elbow JIC37 joints, DN25, total length 864mm

Rated Working Pressure: 16 bar

Burst Pressure: ≥64 bar

Working Temperature Range: ‑30℃ ~ +135℃

Media Compatibility: Compressor lubricating mineral oil & synthetic oil

Connection Type: Fixed crimped metal end connections, ready‑to‑install assembly

Service Life: 8000 working hours under normal operating conditions

Main Features

Integral crimped hose assembly, direct replacement for original equipment, no additional processing required for on‑site installation.

Multi‑ply steel‑wire braid reinforcement structure, excellent pressure‑bearing performance, resist pressure pulse impact from compressor oil circuit.

High‑temperature‑resistant rubber inner layer, stable performance under long‑term hot‑oil circulation, anti‑aging and oil‑swell resistant.

Galvanized metal double‑end 90‑degree elbow JIC37 fittings, good corrosion resistance, adapt to compact installation space, effectively avoid leakage at crimp joint.

Flexible bending property, absorbs unit vibration, reduces stress load on pipeline connection points..

Application Industry

Widely used in machinery manufacturing, electronics, food, pharmaceutical, packaging and other industrial compressed‑air stations.

Brief Summary

It transports high‑temperature lubricating oil inside compressor unit, absorbs equipment vibration, prevents oil‑circuit leakage, guarantees stable and safe compressor operation.
