Part No: 22978126

Product Name: Scavenge Oil Return Metal Tube Assembly

Tube Body Material: Copper‑alloy metal tube, formed integrated bent pipe with two‑end formed connection joints

Connection Type: Flared end connections, direct fitting installation

Nominal Size: 1/4 inch tube diameter

Rated Working Pressure: 16 bar

Burst Pressure: ≥64 bar

Working Temperature Range: ‑30℃ ~ +135℃

Media Compatibility: Compressor lubricating mineral oil & synthetic oil

Service Life: 8000 working hours under normal operating conditions

Main Features

Integral bent metal tubing assembly, direct replacement for original spare parts, no secondary bending or processing required for field installation.

Copper‑alloy tube body features good vibration‑resistance, anti‑fatigue performance, adapts to unit running vibration.

High temperature and oil corrosion resistant material, stable long‑term operation under hot oil circulation environment.

Precision flared forming ends, reliable sealing performance, effectively eliminate oil leakage risk at connection joints.

Accurate bending dimension, perfectly matches separator tank scavenge oil return circuit layout.

Application Industry

Widely used in machinery manufacturing, automotive processing, electronics, food, pharmaceutical, packaging and other industrial compressed‑air stations.

Brief Summary

It drains residual separated oil from separator tank inner cavity back to main circuit, prevents excess oil carry‑over, guarantees stable and safe compressor operation。
