Hoses, Piping & Tubes

Part No: 1621202700

Hose Body Material: High‑temperature resistant synthetic rubber, multi‑layer steel wire braid reinforcement

Fitting Material: Carbon steel galvanized end fittings, crimped integrated assembly, one straight joint, one 90° elbow joint

Rated Working Pressure: 16 bar

Burst Pressure: ≥64 bar

Working Temperature Range: ‑30℃ ~ +180℃

Media Compatibility: High‑temperature compressed air mixed with compressor lubricant oil

Connection Type: Fixed crimped metal end connections, ready‑to‑install assembly

Service Life: 8000 working hours under normal operating conditions

Main Features

Integral crimped high‑temperature hose assembly, direct replacement for original equipment, no additional processing required for on‑site installation.

Multi‑ply steel‑wire braid reinforcement structure, excellent pressure‑bearing performance, resist pressure pulse impact from compressor discharge side.

Special high‑temperature‑resistant rubber inner layer, stable performance under long‑term high‑temperature air‑oil mixed medium, anti‑aging and oil‑swell resistant.

Galvanized metal fittings with 90° elbow design, good corrosion resistance, adapt to compact internal pipeline layout, effectively avoid leakage at crimp joint.

Good flexible bending performance, absorbs unit vibration and thermal expansion displacement, reduces stress load on pipeline connection points.

Strict pressure‑tested and air‑tightness inspected before delivery to eliminate hidden risks of oil and air leakage.

Application Industry

Widely used in machinery manufacturing, electronics, food, pharmaceutical, packaging and other industrial compressed‑air stations.

Brief Summary

It transports high‑temperature air‑oil mixture from air end to separator tank, absorbs equipment vibration and thermal deformation, prevents medium leakage, guarantees stable and safe compressor operation.
