Hoses, Piping & Tubes

Part No: 1621057600

Hose Body Material: High‑temperature resistant synthetic rubber, multi‑layer steel wire braid reinforcement, blue outer protective cover, DN25 size

Fitting Material: Carbon steel galvanized crimped integrated assembly, female thread connection ends

Rated Working Pressure: 16 bar

Burst Pressure: ≥64 bar

Working Temperature Range: ‑30℃ ~ +135℃

Media Compatibility: Compressor lubricating mineral oil & synthetic oil

Connection Type: Fixed crimped metal end connections, ready‑to‑install assembly

Service Life: 8000 working hours under normal operating conditions

Main Features

Multi‑ply steel‑wire braid reinforcement structure, excellent pressure‑bearing performance, resist pressure pulse impact from compressor oil circuit.

High‑temperature‑resistant rubber inner layer, stable performance under long‑term hot‑oil circulation, anti‑aging and oil‑swell resistant.

Galvanized metal threaded fittings, good corrosion resistance, adapt to compact internal layout, effectively avoid leakage at crimp joint.

Flexible bending property, absorbs unit vibration, reduces stress load on pipeline connection points.

Strict pressure‑tested before delivery to eliminate hidden risks of oil leakage.

Application Industry

Widely used in machinery manufacturing, electronics, food, pharmaceutical, packaging and other industrial compressed‑air stations.

Brief Summary

It transports high‑temperature lubricating oil inside compressor unit, absorbs equipment vibration, prevents oil‑circuit leakage, guarantees stable and safe compressor operation.
