Hoses, Piping & Tubes

Part No: 1613718500

Hose Body Material: High‑strength reinforced rubber, corrugated flexible structure, black outer cover

Fitting Material: Integrated rubber flanged ends, hose clamp connection

Rated Working Pressure: 10 bar

Burst Pressure: ≥40 bar

Working Temperature Range: ‑40℃ ~ +120℃

Media Compatibility: Compressor intake air

Connection Type: Hose clamp fixed installation, ready‑to‑install assembly

Service Life: 8000 working hours under normal operating conditions

Main Features

Integral corrugated suction hose assembly, direct replacement for original equipment, quick on‑site installation.

Reinforced multi‑layer rubber structure, excellent vibration‑absorbing performance, effectively isolate unit vibration.

Good high‑temperature and aging‑resistant property, stable performance under long‑term intake air circulation.

Integrated end interface, match original hose clamp for reliable sealing, prevent air leakage at connection position.

Flexible bending property, compensate assembly tolerance, reduce stress load on pipeline connection points.

Application Industry

Widely used in machinery manufacturing, electronics, food, pharmaceutical, packaging and other industrial compressed‑air stations.

Brief Summary

It transports intake air to airend, absorbs unit vibration, prevents air leakage, guarantees stable and safe compressor operation.
