SM9345 Coalescing Filter

Model : SM9345

Type : Coalescing Filters

Replacement for : SM9345

Efficiently removes liquid water droplets, oil aerosol mist and fine solid particulates from compressed‑air, protects downstream spraying equipment, pneumatic valves and precision instruments.

Part numbers marked "replacement" are not affiliated with the original manufacture.

Send Inquiry Now

Description

Main Features

Part number：SM9345

Type：coalescing precision filter element；Filter media：graded‑density borosilicate glass‑fiber；metal reinforced end‑caps

Max working pressure：16bar；Working temperature：1.5‑65℃

Filtration grade：coalescing grade；residual oil content ≤0.1mg/m³

Function：filter fine solid particles, separate oil‑water aerosol mist in compressed‑air

Applications

Maintenance suggestion: replace element when ΔP＞0.07MPa；inspect end‑cap sealing ring condition；recommended service cycle 8000 working‑hours or maximum 12‑month calendar life; shall not exceed rated flow and working pressure
