Coalescing Filters

Part No: HP2040X1

Filtration Accuracy: 1μm

Residual Oil Aerosol: 0.5ppm

Rated Flow: 40m³/h

Compatible Housing: Walker 50HP50X1 high‑pressure filter housing

Working Temperature: ‑10℃ ~ +65℃

Dimension: Φ54×121mm

Service Life: 5000‑8000h, replace when pressure drop reaches 0.35bar

Filter Media: Imported composite glass fiber

Main Features

X1‑grade high‑pressure coalescing element for 50bar working condition, removes solid particles, liquid water and oil‑mist aerosol from compressed air

Oil‑repellent & water‑repellent glass‑fiber media, low pressure drop and excellent air permeability to reduce high‑pressure compressor energy consumption

Gradient multi‑layer structure, high dirt‑holding capacity, anti‑fiber shedding, stable filtration performance under high‑pressure condition

Heavy‑duty inner & outer support mesh against high‑pressure air‑flow impact

Designed for high‑pressure compressor systems, safeguards high‑pressure pneumatic components and high‑pressure painting equipment against oil‑water contamination

Application Industries

High‑pressure air‑compressor post‑treatment system, high‑pressure pneumatic equipment, high‑pressure painting, laboratory high‑pressure air supply, general‑industry high‑pressure gas supply, chemical industry

Product Summary

With 1μm filtration rating, it fits 50bar filter housing and removes particles, moisture and oil mist to deliver clean high‑pressure compressed air for heavy‑duty industrial applications, direct replacement for original filter element
