Coalescing Filters

Model No: F2124IH

Filter Type: High Efficiency Coalescing Oil Removal Filter

Filter Media: HV Borosilicate Composite Micro Glass Fiber

Filtration Precision: 0.01μm

Max Outlet Residual Oil: ≤0.01PPM

Max Working Pressure: 1.0MPa

Max Working Temperature: ≤80℃

Standard Service Life: 3500–4000 Working Hours

Product Features

Ultra-high oil removal grade, filtration precision 0.01μm, outlet residual oil ≤0.01ppm, oil separation efficiency ≥99.99%

Deep uniform pleated large-area media, excellent oil & water storage capacity, service life 3500–4000 working hours

Thickened stainless steel inner support cage, strong compression resistance, no collapse/deformation under long-term high airflow impact

Imported HV microfiber media, outstanding high temperature & lubricant corrosion resistance, zero fiber shedding to avoid secondary air pollution

Optimized internal streamline channel keeps ultra-low initial pressure drop, greatly reduces whole air system power consumption

Integral elastic sealing end cap, tight fit with F2124IH filter housing, thoroughly prevent unfiltered air bypass leakage

Large flow capacity up to 1250SCFM, max working pressure 1.0MPa, working temperature range 0–80℃

Special pre-filter design, effectively guard adsorption dryers and cut maintenance frequency of drying equipment

Application Scope

Matched with large-power screw air compressors, widely applied in precision electronics assembly, pharmaceutical production, food & beverage processing, automobile high-gloss spraying, laser cutting workshops, laboratory high-purity gas supply, chemical, textile and heavy machinery manufacturing factories.
